GW-9500MH-5DR

Basic Information

• Case Size: 56.7 × 52.7 × 14.8 mm

• Weight: 88 g

• Case and bezel material: Bio-based Carbon / Stainless steel

• Band: Bio-based resin band

• Construction: Shock Resistant, Mud Resistant, Carbon Core Guard structure

• Water resistance: 200-meter water resistance

• Time adjustment: Radio-controlled Watch; Multi band 6

• Power supply: Tough Solar (Solar powered)

Sensor Features

• Digital compass: Measures and displays direction as one of 16 points; measuring range: 0 to 359°; measuring unit: 1°; 60 seconds continuous measurement; graphic direction pointer; bidirectional calibration; magnetic declination correction; bearing memory

• Altimeter: Measuring range: -700 to 10,000 m (-2,300 to 32,800 ft.); measuring unit: 1 m (5 ft.); manual memory measurements (up to 30 records, each including altitude, date, time); auto log data (high/low altitudes, auto cumulative ascent and descent); trek log data (up to 14 records of high/low altitudes, auto cumulative ascent and descent of particular treks); relative altitude readings (-3,000 to 3,000 m); selectable measurement interval: 5 seconds or 2 minutes (1 second for the first 3 minutes only); changeover between meters (m) and feet (ft.)

• Barometer: Display range: 260 to 1,100 hPa (7.65 to 32.45 inHg); display unit: 1 hPa (0.05 inHg); atmospheric pressure tendency graph (past 42 hours of readings); atmospheric pressure differential graphic; barometric pressure tendency information alarm (beep and arrow indicate significant changes in pressure); changeover between hPa and inHg

• Thermometer: Display range: -10 to 60°C (14 to 140°F); display unit: 0.1°C (0.2°F); changeover between Celsius (°C) and Fahrenheit (°F)

Exterior

• Glass: Mineral Glass

• Surface treatment: Light yellow gold ion plated bezel

• Compatible band size: 145 to 215 mm

Watch Features

World Time

* World time: 31 time zones (48 cities + coordinated universal time), daylight saving on/off

Sunrise/Sunset Display

* Sunrise/sunset time display: Sunrise and sunset times for a specific date

Stopwatch

• Stopwatch: 1/10-second stopwatch

• Measuring capacity: 999:59'59.9''

• Measuring modes: Elapsed time, split time, 1st–2nd place times

Timer

• Timer: Countdown timer

• Measuring unit: 1 second

• Countdown range: 24 hours

• Countdown start time setting range: 1 minute to 24 hours (1-minute increments and 1-hour increments)

Alarm/Hourly Time Signal

• Alarm: 5 daily alarms (with 1 snooze alarm)

• Hourly time signal

Light

• Light: LED backlight (Super Illuminator)

• Full auto LED light: Selectable illumination duration (1.5 seconds or 3 seconds), afterglow

• Light color: White LED

Calendar

* Calendar: Full auto-calendar (to year 2099)

Mute Feature

* Mute feature: Button operation tone on/off

Energy Saving Feature

* Power Saving: Turns off the display when the watch is left in the dark

Battery Display/Alert

* Battery level indicator

Run Time

* Approx. battery operating time: 6 months on rechargeable battery (normal use without exposure to light after full charge); 26 months on rechargeable battery (stored in total darkness with the power save function on after full charge)

Accuracy

* Accuracy: ±15 seconds per month (with no signal calibration)

Other Features

• 12/24-hour format

• Regular timekeeping: Hour, minute, second, PM, month, date, day

• Duplex LC display

Time Adjustment Details

* Time calibration signal reception: Auto receive up to six times a day (remaining auto receives canceled as soon as one is successful); five times a day for the Chinese calibration signal; manual receive; latest signal reception results

* Time calibration signals:

• DCF77: Mainflingen, Germany — 77.5 kHz

• MSF: Anthorn, England — 60.0 kHz

• WWVB: Fort Collins, United States — 60.0 kHz

• JJY: Fukushima, Fukuoka/Saga, Japan — 40.0 kHz (Fukushima) / 60.0 kHz (Fukuoka/Saga)

• BPC: Shangqiu City, Henan Province, China — 68.5 kHz
