GW-9500MRY-1A9DR

Basic Information

• Case Size: 56.7 × 52.7 × 14.8 mm

• Weight: 88 g

• Case and Bezel Material: Bio-based Carbon / Bio-based resin / Stainless steel

• Band: Bio-based resin band

• Construction: Shock Resistant

• Construction: Mud Resistant

• Construction: Carbon Core Guard structure

• Water Resistance: 200-meter water resistance

• Time Adjustment: Radio-controlled Watch; Multi band 6

• Power Supply and Battery Life: Tough Solar (Solar powered)

Sensor Feature

Digital Compass

• Measures and displays direction as one of 16 points

• Measuring Range: 0 to 359°

• Measuring Unit: 1°

• 60 seconds continuous measurement

• Graphic direction pointer

• Bidirectional calibration

• Magnetic declination correction

• Bearing memory

Altimeter

• Measuring Range: -700 to 10,000 m (-2,300 to 32,800 ft.)

• Measuring Unit: 1 m (5 ft.)

• Manual memory measurements (up to 30 records, each including altitude, date, time)

• Auto log data (High/low altitudes, auto cumulative ascent and descent)

• Trek log data (up to 14 records of high/low altitudes, auto cumulative ascent and descent of particular treks)

• Relative altitude readings: -3,000 to 3,000 m

• Selectable measurement interval: 5 seconds or 2 minutes

• 1 second measurement for first 3 minutes only

• Changeover between meters (m) and feet (ft)

Barometer

• Display Range: 260 to 1,100 hPa (7.65 to 32.45 inHg)

• Display Unit: 1 hPa (0.05 inHg)

• Atmospheric pressure tendency graph (Past 42 hours of readings)

• Atmospheric pressure differential graphic

• Barometric pressure tendency information alarm (beep and arrow indicate significant changes in pressure)

• Changeover between hPa and inHg

Thermometer

• Display Range: -10 to 60℃ (14 to 140℉)

• Display Unit: 0.1℃ (0.2℉)

• Changeover between Celsius (℃) and Fahrenheit (℉)

Exterior

• Glass: Mineral Glass

• Surface Treatment: Black ion plated bezel

• Compatible Band Size: 145 to 215 mm

Watch Features

World Time

• World time

• 31 time zones (48 cities + coordinated universal time), daylight saving on/off

Sunrise/Sunset Display

• Sunrise, sunset time display

• Sunrise time and sunset time for specific date

Stopwatch

• 1/10-second stopwatch

• Measuring Capacity: 999:59'59.9''

• Measuring Modes: Elapsed time, split time, 1st-2nd place times

Timer

• Countdown timer

• Measuring Unit: 1 second

• Countdown Start Time Setting Range: 24 hours

• Countdown Start Time Setting Range: 1 minute to 24 hours (1-minute increments and 1-hour increments)

Alarm/Hourly Time Signal

• 5 daily alarms (with 1 snooze alarm)

• Hourly time signal

Light

• LED backlight (Super Illuminator)

• Full auto LED light

• Selectable illumination duration (1.5 seconds or 3 seconds)

• Afterglow

Light Color

• LED: White

Calendar

• Full auto-calendar (to year 2099)

Mute Feature

• Button operation tone on/off

Energy Saving Feature

• Power Saving (Turns off the display when the watch is left in the dark)

Battery Display/Alert

• Battery level indicator

Run Time

• Approx. battery operating time:

  • 6 months on rechargeable battery (operation period with normal use without exposure to light after full charge)

  • 26 months on rechargeable battery (operation period when stored in total darkness with the power save function on after full charge)

Accuracy

• Accuracy: ±15 seconds per month (with no signal calibration)

Other Features

• 12/24-hour format

• Regular timekeeping:

  • Hour, minute, second, pm, month, date, day

• Duplex LC display

Time Adjustment Details

Time Calibration Signal Reception

• Auto receive up to six times a day (remaining auto receives canceled as soon as one is successful)

• 5 times a day for the Chinese calibration signal

• Manual receive

• Latest signal reception results

Time Calibration Signals

• Station Name: DCF77 (Mainflingen, Germany)

  • Frequency: 77.5 kHz

• Station Name: MSF (Anthorn, England)

  • Frequency: 60.0 kHz

• Station Name: WWVB (Fort Collins, United States)

  • Frequency: 60.0 kHz

• Station Name: JJY (Fukushima, Fukuoka/Saga, Japan)

  • Frequency: 40.0 kHz (Fukushima) / 60.0 kHz (Fukuoka/Saga)

• Station Name: BPC (Shangqiu City, Henan Province, China)

  • Frequency: 68.5 kHz
